Main Technical Parameters:
Model No. | YTZ32-1000D |
Nominal pressure | 10000kn |
Hydraulic cushion force | 1500kn |
Capacity | 25Mpa |
Working table size | 3500x2250mm |
Hydraulic cushion size | 2500x1500mm |
Max opening height | 2400mm |
Ram stroke | 1000mm |
Hydraulic cushion stroke | 300mm |
Ram speed | Down: 200mm/s |
Moving direction of moveable working table | Forward |
Moveable working table | 1 set |
Max capacity of moveable working table | 40t |
Travel speed of moveable working table | 40mm/s |
Travel distance of moveable working table | ≥2350mm |
Machine height | 8700mm |
Motor power | 135kw |
